Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 3 CPU ARCHITECTURE
R01UH0959EJ0110 Rev.1.10 Page 74 of 765
Mar 7, 2023
Caution Do not access addresses to which extended SFRs (2nd SFRs) are not assigned.
Remark For SFRs in the SFR area, see 3.2.4 Special function register (SFR) area.
Table 3-6. Extended SFR (2nd SFR) List (1/4)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After Reset
1-bit 8-bit 16-bit
F0010H A/D converter mode register 2 ADM2 R/W   — 00H
F0013H A/D test register ADTES R/W —  — 00H
F0030H Pull-up resistor option register 0 PU0 R/W   — 00H
F0032H Pull-up resistor option register 2 PU2 R/W   — 00H
F0034H Pull-up resistor option register 4 PU4 R/W   — 01H
F003CH Pull-up resistor option register 12 PU12 R/W   — 00H
F004EH Port input mode register 14 PIM14 R/W   — 00H
F0050H Port output mode register 0 POM0 R/W   — 00H
F0052H Port output mode register 2 POM2 R/W   — 00H
F0054H Port output mode register 4 POM4 R/W   — 00H
F0060H Port mode control register 0 PMC0 R/W   — FFH
F0062H Port mode control register 2 PMC2 R/W   — FFH
F0070H Noise filter enable register 0 NFEN0 R/W   — 00H
F0071H Noise filter enable register 1 NFEN1 R/W   — 00H
F0073H Input switch control register ISC R/W   — 00H
F0075H Peripheral I/O redirection register 2 PIOR2 R/W —  — 00H
F0077H Peripheral I/O redirection register 0 PIOR0 R/W —  — 00H
F0079H Peripheral I/O redirection register 1 PIOR1 R/W —  — 00H
F007CH Peripheral I/O redirection register 3 PIOR3 R/W —  — 00H
F00A0H High-speed on-chip oscillator trimming register HIOTRM R/W —  — Undefined
Note 1
F00A8H High-speed on-chip oscillator frequency select
register
HOCODIV R/W —  — Undefined
Note 2
F00BEH Flash sequencer frequency setting register FSSET R/W —  — 00H
F00C0H Flash programming mode control register FLPMC R/W —  — 08H
F00C1H Flash sequencer control register FSSQ R/W —  — 00H
F00C2H Flash address pointer L FLAPL R/W —  — 00H
F00C3H Flash address pointer H FLAPH R/W —  — 00H
F00C4H Flash end address pointer L FLSEDL R/W —  — 00H
F00C5H Flash end address pointer H FLSEDH R/W —  — 00H
F00C6H Flash sequencer status register L FSASTL R —  — 00H
F00C7H Flash sequence status register H FSASTH R —  — 00H
F00C8H Flash write buffer register LL FLWLL R/W —  — 00H
F00C9H Flash write buffer register LH FLWLH R/W —  — 00H
F00CAH Flash write buffer register HL FLWHL R/W —  — 00H
F00CBH Flash write buffer register HH FLWHH R/W —  — 00H
F00F0H Peripheral enable register 0 PER0 R/W   — 00H
F00F3H Operation speed mode control register OSMC R/W —  — 00H
F00FEH BCD adjust result register BCDADJ R —  — Undefined
