Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 3 CPU ARCHITECTURE
R01UH0959EJ0110 Rev.1.10 Page 75 of 765
Mar 7, 2023
Table 3-6. Extended SFR (2nd SFR) List (2/4)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After Reset
1-bit 8-bit 16-bit
F0100H Serial status register 00 SSR00L SSR00 R —   0000H
F0101H — — —
F0102H Serial status register 01 SSR01L SSR01 R —   0000H
F0103H — — —
F0108H Serial flag clear trigger register 00 SIR00L SIR00 R/W —   0000H
F0109H — — —
F010AH Serial flag clear trigger register 01 SIR01L SIR01 R/W —   0000H
F010BH — — —
F0110H Serial mode register 00 SMR00 R/W — —  0020H
F0111H
F0112H Serial mode register 01 SMR01 R/W — —  0020H
F0113H
F0118H Serial communication operation setting register 00 SCR00 R/W — —  0087H
F0119H
F011AH Serial communication operation setting register 01 SCR01 R/W — —  0087H
F011BH
F0120H Serial channel enable status register 0 SE0L SE0 R    0000H
F0121H — — —
F0122H Serial channel start register 0 SS0L SS0 R/W    0000H
F0123H — — —
F0124H Serial channel stop register 0 ST0L ST0 R/W    0000H
F0125H — — —
F0126H Serial clock select register 0 SPS0L SPS0 R/W —   0000H
F0127H — — —
F0128H Serial output register 0 SO0 R/W — —  0303H
F0129H
F012AH Serial output enable register 0 SOE0L SOE0 R/W    0000H
F012BH — — —
F0134H Serial output level register 0 SOL0L SOL0 R/W —   0000H
F0135H — ― ―
F0180H Timer counter register 00 TCR00 R — —  FFFFH
F0181H
F0182H Timer counter register 01 TCR01 R — —  FFFFH
F0183H
F0184H Timer counter register 02 TCR02 R — —  FFFFH
F0185H
F0186H Timer counter register 03 TCR03 R — —  FFFFH
F0187H
F0188H Timer counter register 04 TCR04 R — —  FFFFH
F0189H
F018AH Timer counter register 05 TCR05 R — —  FFFFH
F018BH
F018CH Timer counter register 06 TCR06 R — —  FFFFH
F018DH
