Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 3 CPU ARCHITECTURE
R01UH0959EJ0110 Rev.1.10 Page 76 of 765
Mar 7, 2023
Table 3-6. Extended SFR (2nd SFR) List (3/4)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After Reset
1-bit 8-bit 16-bit
F018EH Timer counter register 07 TCR07 R — —  FFFFH
F018FH
F0190H Timer mode register 00 TMR00 R/W — —  0000H
F0191H
F0192H Timer mode register 01 TMR01 R/W — —  0000H
F0193H
F0194H Timer mode register 02 TMR02 R/W — —  0000H
F0195H
F0196H Timer mode register 03 TMR03 R/W — —  0000H
F0197H
F0198H Timer mode register 04 TMR04 R/W — —  0000H
F0199H
F019AH Timer mode register 05 TMR05 R/W — —  0000H
F019BH
F019CH Timer mode register 06 TMR06 R/W — —  0000H
F019DH
F019EH Timer mode register 07 TMR07 R/W — —  0000H
F019FH
F01A0H Timer status register 00 TSR00L TSR00 R —   0000H
F01A1H — — —
F01A2H Timer status register 01 TSR01L TSR01 R —   0000H
F01A3H — — —
F01A4H Timer status register 02 TSR02L TSR02 R —   0000H
F01A5H — — —
F01A6H Timer status register 03 TSR03L TSR03 R —   0000H
F01A7H — — —
F01A8H Timer status register 04 TSR04L TSR04 R —   0000H
F01A9H — — —
F01AAH Timer status register 05 TSR05L TSR05 R —   0000H
F01ABH — — —
F01ACH Timer status register 06 TSR06L TSR06 R —   0000H
F01ADH — — —
F01AEH Timer status register 07 TSR07L TSR07 R —   0000H
F01AFH — — —
F01B0H Timer channel enable status register 0 TE0L TE0 R    0000H
F01B1H — — —
F01B2H Timer channel start register 0 TS0L TS0 R/W    0000H
F01B3H — — —
F01B4H Timer channel stop register 0 TT0L TT0 R/W    0000H
F01B5H — — —
F01B6H Timer clock select register 0 TPS0 R/W — —  0000H
F01B7H
F01B8H Timer output register 0 TO0L TO0 R/W —   0000H
F01B9H — — —
