RL78/G15 CHAPTER 24 ELECTRICAL SPECIFICATIONS (T

= −40 to +105°C, TA = −40 to +125°C)

R01UH0959EJ0110 Rev.1.10 Page 743 of 765

Mar 7, 2023

Remark 1. p: CSI number (p = 00, 01), n: Channel number (n = 0, 1)

Remark 2. f

MCK

: Serial array unit operation clock frequency

(Operation clock to be set by serial clock select register 0 (SPS0) and the CKS0n bit of serial mode

Simplified SPI (CSI) mode connection diagram

RL78

microcontroller

User device

SCKp

SOp

SCK

SIp

Simplified SPI (CSI) mode serial transfer timing

(When DAP0n = 0 and CKP0n = 0, or DAP0n = 1 and CKP0n = 1)

Input data

SIp

SOp

KCY1,

KL1

, 2

KH1, 2

SIK1, 2

KSI1, 2

KSO1, 2

SCKp

Output data

Remark p: CSI number (p = 00, 01), n: Channel number (n = 0, 1)
