Connect switch K3 to X3, and set [E1.02] = '3: Multi-speed control input 3'.
Connect switch K4 to X4, and set [E1.03] = '35: Forward running (FWD)'.
Connect switch K5 to X5, and set [E1.04] = '36: Reverse running (REV)'.
K5 K4 K3 K2 K1 Setting frequency Acc. / Dec. time
See chapter "2-wire
control mode 1" on
page 168 and chap-
ter "2-wire control
mode 2 (Forward /
reverse, run / stop)"
on page 169
Open Open Open [E0.07] [E0.26] / [E0.27]
Open Open Closed [E3.40] [E3.10] / [E3.11]
Open Closed Open [E3.41] [E3.12] / [E3.13]
Open Closed Closed [E3.42] [E3.14] / [E3.15]
Closed Open Open [E3.43] [E3.16] / [E3.17]
Closed Open Closed [E3.44] [E3.18] / [E3.19]
Closed Closed Open [E3.45] [E3.20] / [E3.21]
Closed Closed Closed [E3.46] [E3.22] / [E3.23]
Tab. 12-5: Multi-speed settings for 8 or less stages
Case 2: 9 or more stages
Set [E1.15] = 4 first.
Connect switch K1 to X1, and set [E1.00] = '1: Multi-speed control input 1'.
Connect switch K2 to X2, and set [E1.01] = '2: Multi-speed control input 2'.
Connect switch K3 to X3, and set [E1.02] = '3: Multi-speed control input 3'.
Connect switch K4 to X4, and set [E1.03] = '4: Multi-speed control input 4'.
Connect switch K5 to X5, and set [E1.04] = '35: Forward running (FWD)'.
K4
K3 K2 K1 Setting frequency Acc. / Dec. time
Open Open Open Open [E0.07] [E0.26] / [E0.27]
Open Open Open Closed [E3.40] [E3.10] / [E3.11]
Open Open Closed Open [E3.41] [E3.12] / [E3.13]
Open Open Closed Closed [E3.42] [E3.14] / [E3.15]
Open Closed Open Open [E3.43] [E3.16] / [E3.17]
Open Closed Open Closed [E3.44] [E3.18] / [E3.19]
Open Closed Closed Open [E3.45] [E3.20] / [E3.21]
Open Closed Closed Closed [E3.46] [E3.22] / [E3.23]
Closed Open Open Open [E3.47] [E0.26] / [E0.27]
Closed Open Open Closed [E3.48] [E3.10] / [E3.11]
Closed Open Closed Open [E3.49] [E3.12] / [E3.13]
Closed Open Closed Closed [E3.50] [E3.14] / [E3.15]
Closed Closed Open Open [E3.51] [E3.16] / [E3.17]
Closed Closed Open Closed [E3.52] [E3.18] / [E3.19]
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
140/389
DOK-RCON03-EFC-X610***-IT05-EN-P
