15 February 2006 MAIL BOX (B762)
1-107
Installation
2. If the Cover Interposer Tray B704 is installed on the B700/B701, remove it.
NOTE: The cover interposer tray and mailbox cannot be installed on the
finisher at the same time.
3. Remove the top cover [A] of the finisher (" x 1).
4. Remove the bracket [B] (" x 1).
B762I102.WMF
[A]
[B]
