ADF
15 February 2006
6-20
6.4.8
ORIGINA
L SIZE DETEC
TION
[A]:
Origi
nal width sensor 1
[B]:
Origi
nal width sensor 2
[C]:
Original
width sens
or 3
[D]:
Original
width sens
or 4
[E]:
B5 length sens
or
[F]:
A4 length sens
or
[G]:
LG length sens
or
W
hen the
lead
ing edge
of
the pap
er pas
ses
the ske
w corre
ction s
enso
r, th
e CPU
reads the
outputs from the
original w
idth and length se
nsors.
Please re
fer to the tabl
e on the nex
t page.
B246D863.
W
MFF
[A]
[B]
[C]
[D]
[E]
[F]
[G]
715
717
