PUNCH UNIT (B702) 15 February 2006
1-86
1.15 PUNCH UNIT (B702)
The Punch Unit B702 can be installed only in the 2000/3000-Sheet Finisher
B700/B701.
1.15.1 ACCESSORIES
Check the accessories and their quantities against the following list.
Description Q’ty
Punchout Waste Unit............................................................... 1
Slide Drive Unit........................................................................ 1
Punch Waste Hopper............................................................... 1
Screws (M3 x 6)....................................................................... 5
Side-to-Side Detection Unit ..................................................... 1
Punching Unit .......................................................................... 1
!WARNING!
Always turn the machine off and unplug the machine before doing any of
the following procedures.
B702I101.WMF
1
2
3
4
5
6
