15 February 2006 3000-SHEET FINISHERS (B468/B469/B674)
1-37
Installation
Installation
!CAUTION
Switch the machine off and unplug the machine before starting the
following procedure.
1. Install the front [A] and rear [B] joint brackets (" x 2 each, M4x 14).
2. Install the ground plate [C] (" x 2, M3 x 6).
B468I003.WMF
[A]
[C]
[B]
