5.6.2 COPIER OUTPUT CHECK: SP5804
1. Open SP mode 5804.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table on the next page.)
3. Press On then press Off to test the selected item.
NOTE: You cannot exit and close this display until you press off to switch off
the output check currently executing. Do not keep an electrical
component switched on for a long time.
No. Description
1 Feed Motor 1
2 Feed Motor 2
3 Feed Motor 3
4 Feed Motor 4
5 By-pass Feed Clutch
6 LCT Paper Feed Motor
9 Pick-up SOL 1
10 Pick-up SOL 2
11 Pick-up SOL 3
12 Pick-up SOL 4
13 By-pass Pick-up SOL
14 LCT Pick-up SOL
17 Reverse Release SOL 1
18 Reverse Release SOL 2
19 Reverse Release SOL 3
20 Reverse Release SOL 4
22 Tandem Connection Release SOL
23 Left Tandem Lock SOL
24 Tandem Transport Motor
27 Relay Motor
28 Main Motor
31 Fusing Exit Motor
39 Registration Motor
40 Guide Plate Release SOL
41 Exit Junction SOL
43 Inverter Duplex Motor
44 Duplex Transport Motor
To Next Page
