INPUT/OUTPUT CHECK 15 February 2006
5-196
No. Description
45 Duplex Entrance Junction Gate SOL
46 Inverter Jogger SOL
47 Duplex Transport CL (B064 only)
52 Development Roller Clutch
53 Development Motor
54 Used Toner Motor
55 Web Motor
56 Toner Bottle Motor
57 Trigger/Separation CL
62 Quenching Lamp
63 Charge Corona
64 Grid Wire
67 Development Bias
69 Transfer Bias
70 ID Sensor LD
72 Xenon Lamp
75 Duplex Unit Fan
76 Main Ventilation Fan
77 Main Suction Fan
78 Main Vacuum Fan
79 OPC Fan
80 FIN Junction SOL
81 FIN Junction SOL (Stapler)
82 FIN End Roller SOL
84 Total Counter
85 FIN Main Motor 1
86 FIN Main Motor 2
87 FIN Exit Motor
88 Booklet Stapler Motors
89 FIN Punch Motor
90 LD DC Lamp DFU
92 FIN Tray Lift Motor
93 FIN Jogger Motor
94 FIN Staple Transport Motor
95 FIN Exhaust Motor
96 FIN Shift Motor
97 FIN Staple Slant Motor
98 Status Lamp (Green)
99 Status Lamp (Red)
100 PTL
To Next Page
