Ricoh MT-C1 - Gigabit Ethernet G381; Accessories; Installation

MFP OPTIONS: B246 SERIES 15 February 2006
1-200
1.24.16 GIGABIT ETHERNET G381
Accessories
Description Q’ty
1. Gigabit Ethernet B381 ...........................................................1
2. Ferrite Core (not used for B234/B235/B236) .........................1
Installation
1. Switch the machine off.
2. If the Ethernet & USB 2.0 card
[A] is installed in B3, remove it
(! x 2).
3. Insert the Gigabit Ethernet
Board [B] into Slot B3 and
fasten it with the screws.
4. Print a configuration page to confirm that the machine recognizes the board:
User Tools > Printer Features > List/Test Print > Configuration Page
G381I101.WMF
[A]
[B]
