3.9 PUNCH UNIT (B531)
The Punch Unit B531 is installed in the 3000 Sheet Finisher B478/B706.
2/3-hole (North America) Punch Hole Positions
2/4-hole (Europe)
Punch Paper Size
2-Hole (NA) A5 ~ A3 SEF, 11" x 17"~5 1/2" x 81/2" SEF
A5 ~ A4 LEF, 8
1/2" x 11" LEF, 51/2" x 81/2" LEF
3-Hole (NA) A3 SEF, B4 SEF, 11" x 17" SEF
A4 LEF, B5 LEF, 8
1/2" x11" LEF
4-Hole ( EUR/A) A3 SEF, 11" x 17" SEF
A4 LEF, 8
1/2" x 11" LEF
Paper Weight
2-Hole (NA)
52 g/m
2
~ 163 g/m
2
(14 ~ 43 lb)
3-Hole (NA)
52 g/m
2
~ 163 g/m
2
(14 ~ 43 lb)
4-Hole ( EUR/A)
52 g/m
2
~ 128 g/m
2
(14 ~ 34 lb)
Punch Waste Hopper Capacity
2-Hole (NA) 10K
3-Hole (NA) 15K
4-Hole ( EUR/A) 15K
Operation Modes All (Shift, Proof, Staple)
DIP SW Settings
The correct DIP SW settings of the Punch Unit 531 are provided in the table below
for your reference only. The DIP switches of these punch units do not need to be
changed at installation, or adjusted for operation.
DIP SW Settings
Punch Unit Unit No.
1 2 3 4
2/3-Hole (NA) B531-17 1 0 1 0
2/4-Hole ( EUR/A) B531-27 1 0 0 1
0: OFF
1: ON
