15 February 2006
PCBS AND HDD
3-125
Replacement
Adjustm
ent
B246 Series: IPU
•
Disconnect AD
F cable
Remove:
•
Rear upper
cover (
x2) (
☛
3.3.5)
•
Rear lower cover (
x2)
(
☛
3.3.5)
Remove:
[A]
Screw
s and swing open the contr
oller
box (
x4).
[B]
Left connector shield (
x2)
[C]
Rig
ht connector shield (
x4)
[D]
IPU boar
d unit (
x7,
x2)
•
Slowly sl
ide the IPU board and
bracket out of the controller box
.
[E] IPU
(
x8
B246R1
102.WMF
B246R91
103.WMF
[A]
[B]
[C]
[D]
[E]
