SCANNER
15 February 2006
3-22
Wire Rem
oval: Front
[A]:
Tension bracket (
x
1, spring x 1)
[B]:
Front wi
re pulley (
x 1)
•
Rem
ove the screw. W
hile pullin
g back on th
e drive shaf
t, remove the
pulley
shaft.
[C]: Scanner
w
ire
B246R923.WMF
[A]
[B]
[C]
250
252
