15 February 2006 MFP OPTIONS: B246 SERIES
1-185
Installation
1.24.8 FILE FORMAT CONVERTER TYPE C B609
ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q’ty
2. File Format Converter (MLB: Media Link Board) ................... 1
Installation
1. Turn the machine off.
2. Remove the cover of Slot A2 [A]
(! x 2).
3. Install the file format converter board
[B] in Slot A2 and attach it with the
screws.
B609I101.WMF
[A]
[B]
