15 February 2006 SCANNER
3-19
Replacement
Adjustment
3.4.9 SCANNER HP SENSOR
Rear upper cover (☛ 3.3.5)
[A]: Sensor bracket and leaf ( x 1)
[B]: Scanner HP sensor ( x 1)
B246R919.WMF
[A]
[B]
