15 February 2006
FUSING UNIT
3-81
Replacement
Adjustm
ent
B140 Series
Remove the fusing uni
t (
☛
3.9.1)
[A]:
Top cover (
x 1)
[B]: Bracket
(
x 1, spri
ng x 1)
[C]: Inner
cov
er
[D]:
Stripper paw
l (spring
x 1). Open the arms to release the str
ipper pawl, and
remove it.
B246R1017.WMF
B246R1019.WMF
[C]
[D]
[A]
[B]
309
311
