15 February 2006
DUPLEX UNIT
3-89
Replacement
Adjustm
ent
Duplex Jogger and Transpor
t Motors
[A]:
Jogger
motor (
x 1,
x 2)
[B]:
Transport motor bracket (
harness x 1,
x 1,
x 3, timi
ng belt x 1)
[C]:
Transport motor (
x 2)
B246R1040.WMF
B246R1041.WMF
[A]
[B]
[C]
317
319
