Ricoh MT-C1 - Usb Host Interface Unit Type a (B825); Accessory Check; Installation

MFP OPTIONS: B246 SERIES 15 February 2006
1-194
1.24.11 USB HOST INTERFACE UNIT TYPE A (B825)
Accessory Check
Check the accessories and their quantities against this list:
Description Q’ty
1. USB Host Interface Type A ................................................... 1
Installation
1. Remove the cover [A] of board Slot B1
(! x2).
2. Install the USB host interface board [B]
in Slot B1 (! x2).
B825I101.WMF
[A]
[B]
