15 February 2006
SCANNER
3-11
Replacement
Adjustm
ent
Top Covers
ADF (
☛
3.4.1)
[A]:
Top inside cover (
x 2
)
[B]:
Top left cover (
x 1)
[C]:
Top right cover (
x 1
)
[D]:
Operation panel (
x 1) (
☛
3.3.1)
3.4.2 FEXPOSURE
GLA
SS
[A]:
Rear scale (
x 3)
[B]:
Left cover (
x 3)
B246R908.WMF
B246R909.WMF
[A]
[B]
[C]
[D]
[A]
[B]
[C]
[D]
239
241
