15 February 2006 PUNCH UNIT (B377)
1-41
Installation
1.7 PUNCH UNIT (B377)
The Punch Unit B377 can be installed only in the 3000-Sheet Finishers
B468/B469/B674.
1.7.1 ACCESSORY CHECK
Check the accessories and their quantities against this list:
Description Q’ty
1. Punch unit.............................................................................. 1
2. Sensor arm ............................................................................ 1
3. Hopper................................................................................... 1
4. Step screw............................................................................. 1
5. Spring .................................................................................... 1
6. Spacer (2 mm)....................................................................... 1
7. Spacer (1 mm)....................................................................... 1
8. Tapping screw - M3 x 8 ......................................................... 1
9. Tapping screw - M3x 10 ........................................................ 2
