15 February 2006
PCBS AND HDD
3-117
Replacement
Adjustm
ent
BCU, IOB: B246 Series
•
Disconnect AD
F cable
Remove:
•
Rear upper
cover (
x2) (
☛
3.3.5)
•
Rear lower cover (
x2)
(
☛
3.3.5)
[A]
BCU scr
ews, connectors (
=
x
1,
x4,
x4
)
[B]
IOB screw
s, connectors (
=
x6,
x
16,
x8
)
•
Separate the BC
U
, IOB
at the edge connector
B246R109A.WMF
[A]
[B]
345
