PCBS AND HDD 15 February 2006
3-130
B246 Series PSU
• Rear upper cover ( x2) (☛3.3.5)
• Rear lower cover ( x2) (☛3.3.5)
• Controller box cover ( x13)
Remove:
[A] PSU ( x4, x7)
B246R101A.WMF
