Ricoh MT-C1 - Ps3 (B525-08)

15 February 2006 MFP OPTIONS: B064 SERIES
1-139
Installation
1.22.3 PS3 (B525-08)
1. Remove the rear upper cover (! x 2).
2. Remove the controller cover (! x 9).
3. Insert the PS3 module [A] into Slot 2.
!CAUTION
Make sure that the DIMM is inserted correctly.( ☛
☛☛
☛1.22.2)
B064I204.WMF
[A]
