15 February 2006 FUSING UNIT
3-63
Replacement
Adjustment
3.9.3 FUSING PRESSURE RELEASE HP SENSOR (B140 SERIES)
Fusing unit (☛ 3.9.1)
[A]: Bracket ( x 2)
[B]: HP sensor (pawls x 4)
B246R988.WMF
[A]
[B]
