Ricoh MT-C1 - Rear Fence Return Sensor Replacement

15 February 2006 PAPER FEED
3-97
Replacement
Adjustment
3.11.2 REAR FENCE RETURN SENSOR REPLACEMENT
Turn off the main switch.
Pull out the tandem feed tray.
[A]: Rear bottom plate ( x 1)
[B]: Return sensor ( x 1).
B246R1054.WMF
[A]
[B]
