15 February 2006 TEST PATTERN PRINTING
5-11
Service
Tables
5.3 TEST PATTERN PRINTING
5.3.1 PRINTING TEST PATTERN: SP2902-003
Some of these test patterns are used for copy image adjustments (☛ 3.14) but
most are used primarily for design testing. These test patterns do not use the IPU.
NOTE: Do not operate the machine until the test pattern is printed out completely.
Otherwise, an SC may occur.
1. Enter the SP mode and select SP2902-003.
2. Enter the number for the test pattern that you want to print and press . (See
the table below.)
3. When you are prompted to confirm your selection, press Yes to select the test
pattern for printing.
4. Press Copy Window to open the copy window, then select the settings for the
test print (paper size, etc.)
5. Press Start C twice (ignore the “Place Original” messages) to start the test
print.
6. After checking the test pattern, press SP Mode (highlighted) to return to the SP
mode display.
7. Exit the SP mode.
