15 February 2006 DEVELOPMENT AND TONER SUPPLY
6-69
Detailed
Descriptions
6.9.4 DEVELOPMENT BIAS
Development power pack [A] applies –550V through terminal [B] to the shaft [C] of
the development roller [D]
Bias is also applied to the lower casing to prevent toner from being attracted back
from the drum.
B246D926.WMF
[C] [B]
[A]
[D]
