Ricoh MT-C1 - Dimensions; B064 Series

INSTALLATION REQUIREMENTS 15 February 2006
1-4
1.1.4 DIMENSIONS
B064 Series
B064I003.WMF
B064I002.WMF
480 mm (18.9")
425 mm (16.7")
1,165 mm (45.9")
314 mm (12.4")
690 mm (27.2")734 mm (28.9")
90 mm (3.5")
1,014 mm (39.9")
1,098 mm (43.2")
750 mm (29.5")
458 mm (18")
620 mm (24.4")
