Ricoh MT-C1 - Finisher Input Check: Sp6117 (B478;B704)

15 February 2006 INPUT/OUTPUT CHECK
5-199
Service
Tables
5.6.5 FINISHER INPUT CHECK: SP6117 (B478/B704)
Reading Class 3
No.
Bit
No.
Description
0 1
7 Stack Feed-out Belt HP Sensor Home position Not home position
6 Not Used
5 Shift Tray Lower Limit 2 Sensor Not detected Detected
4 Shift Tray Lower Limit 3 Sensor Not detected Detected
3 Stapler Tray Exit Sensor Paper not detected Paper detected
2 Shift Tray Exit Sensor Paper detected Paper not detected
1 Upper Tray Exit Sensor Paper detected Paper not detected
1
0 Entrance Sensor Paper not detected Paper detected
7 Not used
6 Front Door Safety Switch Door closed Door open
5 Stapler Tray Paper Sensor Paper not detected Paper detected
4 Staple End Sensor Not end End
3 Staple Hammer HP Sensor Home position Not home position
2 Stapler HP Sensor Not home position Home position
1 Shift Tray Half-turn Sensor Home position Not home position
2
0 Jogger HP Sensor Not home position Home position
7 Not Used
6 Staple Cartridge Set Sensor Set Not set
5 Staple Mode HP Sensor 2 Not detected Detected
4 Staple Mode HP Sensor 1 Not detected Detected
3 Not Used
2 Punch Waste Hopper Sensor Not full Full
1 Punch HP1 Sensor Home position Not home position
3
0 Punch Unit Connection Connected Not connected
7 Stapler Ready Ready Not ready
6 Stapler Return Sensor Not detected Detected
5 Exit Guide Open Sensor Home position Not home position
4 Stack Plate –Center HP Sensor Not home position Home position
3 Pre-stack Tray Paper Sensor Paper not detected Paper detected
2 Staple Waste Hopper Sensor Not full Full
1 Stapler Rotation HP Sensor Not home position Home position
4
0 Upper Tray Limit Sensor Not full Full
7 Punch HP 2 Sensor Home position Not home position
6 Not Used
5
Shift Lower Limit - Large Paper
Sensor
Not detected Detected
4 Shift Mode HP Sensor Not detected Detected
3 Stacking Roller HP Sensor Home position Not home position
2 Positioning Roller HP Sensor Not home position Home position
1 Stack Plate – Rear HP Sensor Not home position Home position
5
0
Stack Plate – Front HP Sensor
Not home position
Home position
