PCBS AND HDD 15 February 2006
3-124
[A]: A1, A2 connector slots assembly ( x 1)
[B]: Connector cover ( x 2)
[C]: Mother board support plate ( x 5)
[D]: Mother board ( x 1)
[E]: Mother board DIMM
B246R1101.WMF
[A]
[B]
[C]
[D]
[E]
