INPUT/OUTPUT CHECK 15 February 2006
5-194
16. Lock Detection 2
Bit Description Reading
0 1
7 Charge Corona Leak Leaked Not leaked
6 Not used
5 Toner Collection Motor Lock Locked Not locked
4 Exhaust Fan Lock Locked Not locked
3 Not used
2 Not used
1 Not used
0 Not used
17. Registration Sensor
Bit Description Reading
0 1
7 Not used
6 Not used
5 Front Door Open Open Closed
4 Copy Tray Full Sensor Not full Full
3 Guide Plate Position Sensor Closed Open
2 Relay Sensor Paper present Paper not present
1 By-pass Paper End Sensor Paper present Paper not present
0 Registration Sensor Paper present Paper not present
18. Original Size Set Sensor
Bit Description Reading
0 1
7 Fusing Unit Set Set Not set
6 Not used
5 Key Counter Set Set Not set
4 Original Length 2 Sensor Paper present Paper not present
3 Original Length 1 Sensor Paper present Paper not present
2 Original Width 3 Sensor Paper present Paper not present
1 Original Width 2 Sensor Paper present Paper not present
0 Original Width 1 Sensor Paper present Paper not present
