APPENDIX 1 (FOR MODEL MT) 30 May, 2002
APPENDIX-6
Code Meaning
0D Paper does not reach the Registration Sensor
0E Paper does not reach the Fusing Exit Sensor
0F Paper does not reach the Exit Unit Entrance Sensor
10 Paper does not reach the Exit Sensor
13 Paper does not reach the Duplex Entrance Sensor
14 Paper does not reach the Duplex Transport Sensor 1
15 Paper does not reach the Duplex Transport Sensor 2
16 Paper does not reach the Duplex Transport Sensor 3
17 Paper does not reach the Duplex Exit Sensor
18 Paper does not reach the Exit Tray Sensor
22 Paper caught at he By-pass Paper End Sensor
35 Paper caught at the 1st Paper Feed Sensor
36 Paper caught at the 2nd Paper Feed Sensor
37 Paper caught at the 3rd Paper Feed Sensor
39 Paper caught at the LCT Paper Feed Sensor
3A Paper Jam at Finisher Exit
3B Paper Jam at Mailbox Entrance
3C Paper caught at the 1st Vertical Transport Sensor
3D Paper caught at the 2nd Vertical Transport Sensor
3E Paper caught at the 3rd Vertical Transport Sensor
42 Paper caught at the Exit Sensor
45 Paper caught at the Duplex Entrance Sensor
47 Paper caught at the Duplex Transport Sensor 2
48 Paper caught at the Duplex Transport Sensor 3
4A Paper caught at the Exit Tray Sensor
65 (79*) Paper caught or does not reach the Finisher Entrance Sensor
66 (7A*) Paper caught or does not reach the Finisher Proof Tray Exit Sensor
67 (7B*) Paper caught or does not reach the Exit Sensor
68 (7C*) Paper caught or does not reach the Booklet Exit Sensor
69 (7D*) Paper caught or does not reach the Paper Height Sensor
6A (7E*) Staple Jam
6E (82*) Paper Jam for the Jogger Motor
F (83*) Paper Jam for the Shift Motor
70 (84*) Paper Jam for the Stapler Movement Motor
71 (85*) Paper Jam for the Stapler Rotation Motor
73 (87*) Paper Jam for the Exit Motor
74 (88*) Paper Jam for the Punch Motor
(7F*) Staple Jam (Booklet)
(80*) Paper Jam at the Saddle Stitch
(86*) Paper Jam for the Booklet Stapler Motor
A1 Paper caught or does not reach the Mailbox Transport Sensor 1
A2 Paper caught or does not reach the Mailbox Transport Sensor 2
A3 Paper caught or does not reach the Mailbox Transport Sensor 3
A4 Paper caught or does not reach the Mailbox Transport Sensor 4
A5 Paper caught or does not reach the Mailbox Transport Sensor 5
*: B468 Finisher
