Operation
Folding the machine out/in
WARNING
Hazard of extremely severe injuries.
– Make sure that there are no persons on the boarding platform.
– The driver is responsible for ensuring that there is nobody in the area between
the safety rail at the boarding steps and the cabin door when lifting or lowering the
cabin.
– Raise driver's cabin up to the end-stop.
Raise/lower driver's cabin
Choose this function with R-Select.
+ key = raise driver's cabin
- key = lower driver's cabin
The driver's cabin may only be lowered or raised when the pickup side sections are
folded out.
– Swing the folding plates out.
Fold plates in/out
Choose this function with R-Select.
+ key = swing the folding plates out (fold up)
- key = swing the folding plates in (fold down)
When swinging up the fold plates, the support feet are simultaneously extended all the
way and both clearing shields are folded out.
