Operation
Folding the machine out/in
(18a) Counterweight arm lock opened
(18b) Counterweight arm lock at the
end-stop
(18c) Counterweight arm lock closed
ATTENTION
When the swivel arm is swung under the counterweight arm, the lock (18a) of the
counterweight arm must be fully open, otherwise the machine might be damaged.
226 / 546
