Operation
Folding the machine out/in
– Use the mini joystick (1) to swivel the counterweight arm somewhat out of the cen-
tral position.
DANGER
A person, swept into the machinery during swivelling of the counterweight arm and
trapped there, might sustain fatal injuries!
– Staying under the counterweight arm when it is swung out is strictly prohibited.
– The machine operator must make sure that no people are located within the swiv-
elling range of the counterweight arm.
Danger of fatal injuries if the machine tips over.
– NEVER swivel the counterweight arm to the same side on which the truck con-
veyor is located.
– Specify loading direction.
Use the X-Y key (16) to select the loading direction. (See Page 164)
