Operation
Folding the machine out/in
loading direction left loading direction right
(1) Pickup
(2) Joystick
(3) Driver's seat
(4) Infeed conveyor
(5) Swivel arm
(6) Truck conveyor
DANGER
A person, swept into the machinery during swivelling of the truck conveyor and
trapped there, might sustain fatal injuries!
– Staying under the truck conveyor when it is swung out is strictly prohibited.
– The machine operator must make sure that no people are located within the swiv-
elling range of the truck conveyor.
Hazard due to electrical current.
– In any case, pay attention to power lines located within the swivelling range of the
truck conveyor. Always keep a sufficient safety distance to these lines. This dis-
tance is always determined by the type of power line and this information must be
acquired from the competent power company.
228 / 546
