ROVEMA CMK - Page 119

Rovema CMK Operator’s Manual
Section 5: Operator Controls
200246 CMK Operators Manual (02/06/2006) 5-51
Buttons and Switches
MAIN DISCONNECT Switch
The MAIN DISCONNECT switch turns the electrical power to the machine on or off.
Turn this switch to the “I” or ON position to connect electrical power to the machine.
Turn this switch to the “O” or OFF position to disconnect electrical power to the
machine.
Figure 5.57
Shows the MAIN DISCONNECT switch located on the electrical enclosure.
MACHINE READY Push-Button
This lighted push-button indicates the operating status of the machine. When this
button is lit, it indicates that the machine is ready to operate. When the button is
flashing, it indicates that the machine is homing. When the button is not lit, it
indicates that there is an active alarm present.
Note: If a fault is present, the Main HMI display will indicate the fault.
Figure 5.58
Shows the MACHINE READY push-button.
