Rovema CMK Operator’s Manual
Section 8: Maintenance
200246 CMK Operators Manual (02/06/2006) 8-13
Other Maintenance Procedures
Replacing the rollers on the insertion slide
• Before replacing the rollers, loosen the nuts (1).
• Replace the rollers that are positioned diagonally (2) by removing
screw (3).
• Replace the rollers that are positioned crossways (4) by loosening the
threaded pin (5) and removing the bolt (6).
• Installation is in the opposite order. After the rollers are replaced, adjust
the guide with nuts (1) so there is only a little play.
