Replacing the Ribbon

132

Load the carbon ribbon in order into the ribbon cover (5).

Pull out some carbon ribbon and tape it to the ribbon core , and then close the

ribbon cover .

8. Turn the dial (6) to rewind the carbon ribbon a few times.

9. Close the top cover.

Push both ends of the top cover, and close it firmly until it clicks.

Questions and Answers:

Need help?

Do you have a question about the SATO CT4-LX and is the answer not in the manual?

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
