SATO CT4-LX User Manual

[Advanced]
178
Set the value '+' to move the offset position in the direction opposite to the feed direction and '-' to
move in the feed direction.
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution Setting range
203 dpi (1 dot = 0.125 mm (0.0049")) -30 to +30 dots
305 dpi (1 dot = 0.083 mm (0.0033")) -45 to +45 dots
• You can change the units to dots, " (inches), or mm in the [System] > [Regional] >
[Unit] menu.
• The changes to this setting are linked and are changed with each of the test print
settings in the [Tools] > [Test Print] menu.
[Pitch]
By adjusting the print position, you can set the print start position to adjust the vertical print position.
Set the value '+' to move print position in the direction opposite to the feed direction and '-' to move in
the feed direction.
(1) Feed direction
The setting range varies depending on the print resolution of the product.
The setting range is as follows:
Resolution Setting range
203 dpi (1 dot = 0.125 mm (0.0049")) -30 to +30 dots
305 dpi (1 dot = 0.083 mm (0.0033")) -45 to +45 dots

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
