[RFID]
210
The setting range is from 0 to +240 mm (9.45").
[Encoding Action]
Set the product's operations when writing data to an inlay in the position specified in [Tag Offset].
Appears when [Tag Offset] is set to something other than 0 mm (0").
The product is set to [Normal Action]. Temporarily stops printing in the position specified in [Tag
Offset], and then writes data to the inlay.
White streaks may occur in the stopped position. Adjust the print layout so that objects, such as
barcodes or text, do not overlap at the stopped position.
[Reader Model]
Shows the RFID module model.
[Reader Version]
Shows the RFID module firmware version.
[View]
Reads and shows the data in the selected memory area of the inlay.
The setting items are as follows:
[Memory Bank]
Set the memory area of the inlay to read.
The readable memory areas are as follows:
• [EPC]
• [TID]
• [USER]
• [PC]
• [RSSI]
[Data Reading]
Tapping [Data Reading] displays up to 192 characters of the data read from the inlay.
Tapping [FEED] feeds media, and displays the data read from the inlay in the next tag.
• If you write an EPC of 64 digits or more, you cannot load TID, USER, PC, or RSSI.
[Filter Function]
Set the filter function according to the RSSI (Received Signal Strength Indication). If the RSSI value
that is read while printing an RFID tag is lower than the specified threshold value, an RFID tag error
occurs. An error message is printed on the inlay/RFID tag that caused the error.
The setting items are as follows:
[RSSI Filter]
Enable or disable the RSSI filter function.
