SATO CT4-LX User Manual

217
Antenna Y Pos.
Adjust the position of the RFID standard antenna in the vertical direction.
The setting range is from 0 to 24 mm (0 to 0.94").
Write Power
Read Power
Tag Offset
Pitch Size
Set the length of the RFID tag.
The setting range varies depending on the print resolution of the product.
The setting range of the RFID tag length is as follows:
Resolution Setting range
203 dpi (1 dot = 0.125 mm (0.0049")) 8 to 1,920 dots
305 dpi (1 dot = 0.083 mm (0.0033")) 12 to 2,880 dots
• You can change the units to dots, " (inches), or mm in the [System] > [Regional] >
[Unit] menu.
• Set a value that includes the liner.
When the settings are complete, tap [Save as], and input a name.
You can enter a maximum of 32 characters. Alphabets, numbers and symbols can be used.
Tap on the on-screen keyboard to confirm.
If you specify a name that is the same as a registered RFID tag model, a confirmation message
appears. To overwrite the settings, tap .
[Delete]
Delete registered RFID tag models.
You can use this if more than one RFID tag model has been registered.
Tap the RFID tag model to delete, and then tap in the confirmation message.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
