SATO CT4-LX User Manual

[Compatible]
248
[SBPL]
Set the compatible mode for SBPL.
The setting items are as follows:
[CODE128(C) Zero Fill]
Set whether to allow odd digits and print the barcode with zero-filling when start code C is used in
CODE128.
Allow odd digits and print the barcode with zero-filling.
Do not allow odd digits. A command error occurs and the data will not be printed.
[Kanji Command]
Set the product behavior when the received data includes the Kanji command <K5>, <K6>, or <K7>.
Change the Kanji commands <K5>, <K6>, and <K7> in the received data to the proper
commands, and then print.
◦ <K5>: 16 x 16 dots Kanji in horizontal line with one-byte character
◦ <K6>: 24 x 24 dots Kanji in horizontal line with one-byte character
◦ <K7>: 22 x 22 dots Kanji in horizontal line
Do not change the Kanji commands <K5>, <K6>, or <K7> in the received data. The product
behavior when it receives these commands is as follows:
◦ <K5>: Print with 40 x 40 dots Kanji in horizontal line.
◦ <K6>: A command error occurs and barcode is not printed.
◦ <K7>: A command error occurs and barcode is not printed.
[Call Font/Logo]
Set how to process the character code specified in recall font & logo <RF> command.
Character codes are processed in little-endian format.
Character codes are processed in big-endian format.

SATO CT4-LX Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fan-fold
Media Thickness	0.0025 to 0.008 inches (0.0635 to 0.2032 mm)
Ribbon Width	0.98 inches (25 mm) to 4.09 inches (104 mm)
Ribbon Length	984 feet
Connectivity	USB, Ethernet, Bluetooth
Supported Barcode Types	PDF417, QR Code
Power Requirements	100-240 VAC, 50/60 Hz
