Parts Identification
34
• The size of the USB memory that can be connected inside the product is as follows:
◦ Length: under 68 mm (2.68") (excludes the metal part of the connector)
◦ Width: under 27.6 mm (1.09")
◦ Thickness: under 8.6 mm (0.34")
(3) Engraved
Indicated by the (ribbon cover open) marks on the combined direct thermal/thermal transfer
model.
(4) Media guide
(5) Platen roller (Consumables)
(6) Top cover
To Next Page
