Shimadzu GC-2014 Instruction Manual

16 Special Functions
16.9 Key Lock and Parameter Lock
268
GC-2014
Q Unlocking the parameters (without password)
If parameters are locked and no password is required, when you select “9. LOCK” from the
[FUNC] key screen, the screen shown in Fig. 16.9.6 appears.
When the parameter are unlocked, the screen shown in Fig. 16.9.4 appears.
Q Unlocking parameters (with password)
If parameters are locked and a password is set, when you select “9. LOCK” from the
[FUNC] key screen, the screen shown in Fig. 16.9.7 appears.
When you input the correct password and press the [Unlock] (PF menu) key, the parameters
are unlocked and the screen shown in Fig. 16.9.4 appears.
Fig. 16.9.6 Parameter unlock screen (without password)
Fig. 16.9.7 Parameter unlock screen (when a password is set)
This screen is displayed
when parameters are locked.
This screen is displayed
when parameters are locked.

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
