17 Printing
17.1 Printing
274
GC-2014
17.1.2.6 Log
From each screen of the GC operation log, the analysis log, the parameter log, the error
log and the diagnostic log, press [Print] (PF menu) to print the parameters displayed on
the screen.
For the analysis log, only the list screen is printed. The contents of the detailed analysis
screen are not printed.
For example, press [Print] (PF menu) from the error log screen, to obtain the following
printed results.
The log items are printed in chronological order, starting from the oldest.
Fig. 17.1.6
- GC ERROT LOG -
TIME OCCURED CODE ERROR MESSAGE (VALUE)
200.05.16 14:21 [E1020] DET1 sensor down error (530.00)
200.05.16 14:27 [E0031] INJ-DET2 A/D error
200.05.16 14:27 [E0032] AUX1-AUX3 A/D error
200.05.16 14:27 [E0011] CAR1 AFC PCB error (7.00)
200.05.16 14:27 [E0030] COL A/D error
200.05.16 14:27 [E0001] DC 5 V range error (8.43)
200.05.16 14:27 [E0002] DC 24 V range error (20.34)
200.05.16 14:27 [E0034] Battery voltage error (0.26)
200.05.16 14:27 [E0005] Room temp range error (84.27)
200.05.16 14:27 [E1019] INJ1 sensor down error (530.00)
200.05.16 14:27 [E1018] COL sensor down error (530.00)
200.05.16 14:27 [E1020] DET1 sensor down error (530.00)
200.05.16 14:28 [E0031] INJ1-DET2 A/D error
200.05.16 14:28 [E0032] AUX1-AUX3 A/D error
200.05.16 14:28 [E0011] CAR1 AFC PCB error (7.00)
NOTE

Shimadzu GC-2014 Specifications

General

Type	Gas Chromatograph
Display	LCD
Maximum Heating Rate	120°C/min
Data Acquisition	Digital
Maximum Number of Detectors	4
Weight	Approx. 45 kg
Carrier Gas	Helium, Nitrogen, Hydrogen
Detector Options	FID, TCD, ECD, FPD
Injection Port	Split/Splitless, On-column
Gas Control	Electronic Flow Control (EFC)
Temperature Programming Rate	0.1 to 120 °C/min
Power Requirements	230 V AC, 50/60 Hz
Detector Temperature Range	Up to 400°C (depending on detector type)
