18 Error Messages
18.1 Error Messages
292
GC-2014
AFC leaks
The pressure cannot reach the set value. Check whether gas is supplied and whether gas is
leaking from connections.
Gas may be leaking in locations other than the ones displayed.
AFC valve leak errors
Gas is flowing even if the pressure is set at 0 kPa or the flow rate is set at 0 ml/min. If there
is no problem in the gas supply, an AFC value error may have occurred. Turn off the system
and contact your Shimadzu representative.
Abnormal component operation
Verify whether gas is supplied stably at the required pressure. If there is no problem in the
gas supply, the control system, such as the APC, may have failed. Turn off the system and
contact your Shimadzu representative.
When errors 2138-2140 occur, carrier gas is not properly supplied. Check the gas remaining
in the gas cylinder and piping connections.
Control setting errors
These messages appear when the temperature control starts without carrier gas control. Set
the setting of the flow controller to “On” or remove unused carrier gas line from the line
configuration.
Code Message CS
2130 CAR1 AFC leaks Yes
2131 CAR2 AFC leaks Yes
Code Message CS
2132 CAR1 AFC valve leaks Yes
2133 CAR2 AFC valve leaks Yes
Code Message CS
2134 CAR1 AFC is out of control Yes
2135 CAR2 AFC is out of control Yes
2136 CAR1 AFC is out of control Yes
2137 CAR2 AFC is out of control Yes
2138 CAR1 prim is out of range No
2139 CAR2 prim is out of range No
2140 CAR3 prim is out of range No
Code Message CS
2141 CAR1 is not controlled No
2142 CAR2 is not controlled No
2143 CAR1 is not controlled No
NOTE
