EM500 Open-Loop Vector Control Inverter User Manual
246
F09.01
Numeric PID Setting
0.0 – PID Setting Feedback Range
F09.03
0.0
●
F09.03
PID Setting Feedback
Range
0.1 - 6000.0
100.0
●
F09.00=0: Numeric PID SettingF09.01
PID setting is done by numeric PID setting, with the specific percentage of
F09.01/F09.03 * 100.00%.
F09.00=1: AI1
F09.00=2: AI2
F09.00=3: AI3
F09.00=4: AI4 (Expansion Card)
The specific percentage of PID setting is directly determined by AI (percentage).
F09.00=5: PULSE High-Frequency Pulse (X7)
The specific percentage of PID setting is directly determined by HDI (percentage).
Please refer to the description of F00.04 for detailed explanations of AI1-AI4 and
X7. When they are used for PID setting, their percentages are set values, with the
maximum output of 100.00%.
F09.00=6: Communication Percentage Setting
The specific percentage of PID setting is directly determined by communication
(percentage).

If inverter is under master-slave communication control (F10.05=1) and present
inverter is a slave (F10.06=0), the set percentage is “700FH (Master-Slave
Communication Setting) * F10.08 (Receiving Proportionality Factor of Slave)”.
The range of 700FH is -100.00% to 100.00%. See Table 12-2 for details.

For general communication (F10.05=0), the feedback percentage is “7005 H
(Communication Setting of Process PID Feedback)”. The range of 7005 H is
-100.00% to 100.00%. See Table 12-2 for details.
No.
Function
Range
Unit
Default
Type
F09.02
PID Feedback Source
1: AI1
2: AI2
1
〇
